800 Communications Systems.
Code Change Summary: Article 800 has been removed and replaced.
In the 2020 NEC®, an almost complete rewrite occurred in Article 800 for communications systems. Prior to the rewrite, the same general requirements appeared over and over through Article 800, 820, 830, and 840.
In the 2020 NEC®, Article 800 contains general requirements used in the other Chapter 8 articles which results in a few less pages between the binding of the new NEC®.
Article 800 applies to communication systems which generally means phone lines, communications circuits, community antenna television and radio distribution systems, network-powered broadband communications systems, and premises-powered broadband communications systems, unless modified by Articles 805, 820, 830, or 840.
Below is a preview of the NEC®. See the actual NEC® text at NFPA.ORG for the complete code section. Once there, click on their link to free access to the 2020 NEC® edition of NFPA 70.
2020 Code Language: N ARTICLE 800 General Requirements for Communications Systems N Part I. General N 800.1 Scope. This article covers general requirements for communications systems. These general requirements apply to communications circuits, community antenna television and radio distribution systems, network-powered broadband communications systems, and premises-powered broadband communications systems, unless modified by Articles 805, 820, 830, or 840. N 800.2 Definitions. The definitions in Part I of Article 100 shall apply throughout Chapter 8. The definitions in 800.2 shall apply only within Chapter 8. N Abandoned Cable. Cable that is not terminated at equipment or is not identified for future use with a tag. N Communications Service Provider. An organization, business, or individual that offers communications service to others. N Exposed (to Accidental Contact). A circuit in such a position that, in case of failure of supports or insulation, contact with another circuit may result. Informational Note: See Part I of Article 100 for two other definitions of Exposed: Exposed (as applied to live parts) and Exposed (as applied to wiring methods). N Point of Entrance. The point within a building at which the wire or cable emerges from an external wall or from a concrete floor slab. N 800.25 Abandoned Cables. The accessible portion of abandoned cables shall be removed. Where cables are identified for future use with a tag, the tag shall be of sufficient durability to withstand the environment involved.
